About HPL Energy Meter - Counter Display CT2M-COUNTER

HPL CT2M Counter Type Energy Meter Specification

General Details

• Model: CT2M
• Type: Electronic Energy Meter (Counter display)
• Application: Industrial LT panels (3 Phase, 4 Wire)
• Mounting: Flush mounted
• Dimensions: 96 96 86 mm

Electrical Specifications

• Voltage Supply: 3 240 V AC
• Frequency: 50 Hz (typical industrial supply)
• Current Rating:
  • CT operated: -/5 A
  • Range: up to 800/5 A

Accuracy & Measurement

• Accuracy Class: Class 1.0
• Measurement: kWh (energy consumption)
• Display Type: Counter type (mechanical-style digital)

Display Details

• Digits:
  • 6 digits (direct reading type)
  • 5+1 digits (CT operated type)

Power & Consumption

• Auxiliary Supply: Not required
• Power Consumption: < 1 Watt per phase
• Universal Supply Option: 80300 V AC/DC

Output & Features

• Pulse Output:
  • Potential-free pulse for external energy monitoring
• Pulse Rate:
  • 1 pulse = 1 kWh (direct)
  • 1 pulse = 100 Wh (CT type)
• Anti-Tamper Features: Yes

Key Features

• Suitable for industrial energy monitoring
• Low power consumption
• No separate auxiliary supply needed
• Simple counter display (robust & reliable)
• Supports external energy totalization via pulse output

Applications

• Industrial LT Panels
• Motor Control Centres (MCC)
• Distribution & Relay Panels
• HVAC Panels
• Genset Panels
• Power generation & distribution systems
