ABB AC DRIVE ACS880-01-061A-3+P944

Name: ABB AC DRIVE ACS880-01-061A-3+P944
Brand: STEPTRONE AUTOMATION
Price: 159139 INR
Availability: InStock

Price 159139 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ABB AC DRIVE ACS880-01-061A-3+P944 Specification

Operating Temperature
-15C to +40C

Power Factor
0.98 (typical)

Surface Finish
Powder Coated

Insulation Material
Polycarbonate

IP Rating
IP21

Feature
EMC filtering, Customizable I/O, Removable Control Panel

Shape
Rectangular

Overheating Protection
Built-in thermal protection

Humidity %
5% to 95% (non-condensing)

Connector Type
Plug-in terminal

Efficiency
Up to 98%

Mounting Type
Wall/Floor Mount

Product Type
AC Frequency Drive

Application
Industrial Motor Control

Protection Level
Overload, Short-circuit, Overvoltage

Frequency (MHz)
50-60 Hz

Rated Voltage
400V AC

Energy Consumption
Optimized according to load

Output Type
Adjustable Frequency Output

Color
White & Black

Dimension (L*W*H)
457 mm x 266 mm x 243 mm

Weight
58 kg

Phase
Three Phase

Input Voltage
380-415V AC

Size
Frame Size R6

Material
Metal / Plastic

No Of Poles
3

Connection Type
Screw Terminal

Cooling Method
Forced Air Cooling

Braking Unit
Optional (Braking chopper built-in with +P944 option)

Motor Power Range
30 kW (Nominal)

Series
ACS880-01

Product Code
ACS880-01-061A-3+P944

Control Method
Direct Torque Control (DTC)

Communication Ports
Modbus RTU, Ethernet (optional),

Display Type
Removable Control Panel with Graphic Display

Standards Compliance
IEC/EN 61800-5-1, CE, UL, cUL

Digital I/O
6 DI, 3 DO

Analog I/O
2 AI, 2 AO

ABB AC DRIVE ACS880-01-061A-3+P944 Trade Information

Minimum Order Quantity
1 Number

Main Domestic Market
All India

About ABB AC DRIVE ACS880-01-061A-3+P944

Experience a paragon of industrial motor control with the ABB AC DRIVE ACS880-01-061A-3+P944, now available for a limited time. This laurate in engineering offers seamless access to direct torque control (DTC) with a nominal motor power range of 30 kW. Peerless in safety and reliability, it boasts overload, short-circuit, and overvoltage protection, complemented by EMC filtering and customizable I/O. With optional Ethernet and built-in braking chopper (+P944), this drive sets the benchmark for top-tier performance and efficiency in demanding industrial applications.

Advanced Performance & Versatile Usage

Ideal for demanding industrial applications, the ABB AC DRIVE ACS880-01-061A-3+P944 excels in precise motor control. Its advanced direct torque control method ensures smooth operation, making it beneficial for heavy-duty machinery, conveyors, and pumps. Used as a primary actuator in automated systems, it offers operational flexibility and high energy efficiency, delivering consistent results in challenging environments across manufacturing and processing sectors.

Certifications, Sampling & Global Exports

The ABB AC DRIVE ACS880-01-061A-3+P944 complies with prime international standards including IEC/EN 61800-5-1, CE, UL, and cUL certifications, ensuring quality and safety. Samples can be shipped promptly for evaluation, supported by reliable transport services. Global export markets include Europe, Asia, and the Middle East, with competitive asking prices available upon request. Partners and suppliers in India and abroad benefit from swift, secure deliveries and comprehensive after-sales support.

FAQ's of ABB AC DRIVE ACS880-01-061A-3+P944:

Q: How does the Direct Torque Control (DTC) method benefit industrial applications?

A: The Direct Torque Control (DTC) method in the ABB AC DRIVE ACS880-01-061A-3+P944 provides rapid and precise control of motor torque and speed, resulting in improved process performance, energy savings, and reduced wear on mechanical components.

Q: What is the process for installing the ACS880-01-061A-3+P944 drive?

A: Installation involves mounting the drive on a wall or floor using its frame size R6, connecting power via screw terminals, and configuring the removable control panel. Follow manufacturer guidelines for safety and ensure operating conditions match the specified range.

Q: Where can I use the ABB AC DRIVE ACS880-01-061A-3+P944?

A: This drive is suitable for industrial motor control applications, such as conveyors, compressors, pumps, and fans, particularly in environments demanding high efficiency and reliability.

Q: What communication options are available on this model?

A: The ACS880-01-061A-3+P944 supports Modbus RTU communication and, optionally, Ethernet, making it easy to integrate with various industrial control systems.

Q: When should the built-in braking chopper (+P944) be utilized?

A: The built-in braking chopper should be used when rapid deceleration of driven motors is required, such as in applications with frequent start-stop cycles or emergency stops.

Q: How does the ACS880-01-061A-3+P944 ensure safety and equipment protection?

A: With built-in protections against overload, short-circuit, overvoltage, and overheating, as well as EMC filtering, this drive ensures a safe and reliable operation under diverse industrial conditions.
